“internal admin password”: NetXploreIt application uses an internal account to access the database for the various user and discovery operations. This fixed internal account is used in order not to depend on a particular user account (whether administrator to end user). This account can not be deleted, however, its password can be changed here.

“Login private key”: NetXploreIt uses an encrypted token to authenticate user requests to the application server. This token is used instead of keeping transmitting the username/password when end users issue requests or commands to the application server,  therefore, protecting their credentials.

We recommend to change this password regularly to further protect the users’ credentials. The administrator can also use the changing of this key to force users to log out, as their previous token will become invalid and they will not be able to use the application.

“max session duration”: Specifies the maximum time for a user session. If this expires for a particular user, the user will get an error message whenever a command is issued. The user then has to log out then log in again to start a new session.

The administrator can use this timer to force users to log out (e.g if 1 min is specified, then any user that has been logged in for more than 1 minute will be forced to log out).

To display the currently defined system credentials, click on the “SYSTEM” header tag, then check the corresponding “show password” box.

To change it, fill in the attribute(s) then click the “OK” button.
